Plate 1. 1. Clinopyroxene (cpx) band in the contact between marble (upper part) and quartz + feldspar-rich metapelite layers (lower part). Sample 161-976E-15R-3, 35-36 cm. Scale bar is 214 µm. 2. Band of massive garnet (grt) in the contact between marble (upper part) and metapelite (lower part). Veins in garnet are filled with plagioclase and opaque minerals. Sample 161-976E-21R-3, 27-31 cm. Scale bar is 214 µm. 3. Coexisting garnet (grt), clinopyroxene (cpx), plagioclase (pl), and pyrite (py) from Zone VI. Sample 161-976B-76R-1, 66-87 cm. Scale bar is 214 µm. 4. Xenomorphic relics of garnet (grt) after breakdown reaction to plagioclase (pl), calcite (cal), and quartz (qtz). Sample 161-976E-22R-2, 90-94 cm. Scale bar is 85 µm.

Plate 1. 4. Xenomorphic relics of garnet (grt) after breakdown reaction to plagioclase (pl), calcite (cal), and quartz (qtz). Sample 161-976E-22R-2, 90-94 cm. Scale bar is 85 µm.
