Plate 2. Selected key textural relationships in the high-grade schist. 1. Garnet I porphyroblast surrounded by an idiomorphic rim of garnet II. Garnet I has graphitic and ilmenite inclusion trails defining a rotated internal foliation (S1) oblique to the

Plate 2. Selected key textural relationships in the high-grade schist. 3. Detail of garnet II rim with graphitic inclusions continuous with the external foliation S₂. Note the change of orientation of inclusion trails from rim (garnet II zone) to the outermost core (garnet I zone). Sample 161-976B-76R-1, 45-49 cm. Plane-polarized light. Scale bar is 200 µm.
