Figure 5. Range chart of important species for the late Neogene to Quaternary biostratigraphy. The arrows indicate biostratigraphic events used for the zonation of Okada and Bukry (1980), and the areas with a horizontal short bar indicate the supplementary events used for the age calibration. The solid lines indicate consistent occurrences, and the dashed lines indicate sporadic occurrences.
