Figure 4. Comparison of field seismic data with synthetic seismogram generated using pseudoporosity and pseudovelocity logs, Site 1032. Pseudoporosity profile (thick line) overlaps with the downhole porosity log (thin line). Pseudovelocity also coincides with the downhole sonic velocity log.
