Plate P2. 1, 2. Cordosphaeridium gracile sample/slide, Sample 171B-1053A-14H-4, 125-129 cm/I (E29). Figure 2 is to the same scale as Figure 1. 3. Corrudinium incompositum sample/slide, Sample 171B-1053A-10H-6, 125-130 cm/I (E35). 4, 5. Cordosphaeridium minimum sample/slide, Sample 171B-1053A-2H-4, 125-130 cm/I (J35). Figure 5 is to the same scale as Figure 4. 6, 7. Cerebrocysta bartonensis sample/slide, Sample 171B-1053A-9H-5, 105-108 cm/I (B35). Figure 7 is to the same scale as Figure 6. 8, 9. Cribroperidinium tenuitabulatum sample/slide, Sample 171B-1053A-11H-4, 125-130 cm/I (F32). Figure 9 is to the same scale as Figure 8. 10. Tectatodinium pellitum sample/slide, Sample 171B-1053A-9H-5, 105-108 cm/I (Y48). 11, 12. Turbiosphaera filosa sample/slide, Sample 171B-1053A-9H-5, 105-108 cm/I (Y29). Figure 12 is to the same scale as Figure 11. 13, 14. Thalassiphora patula sample/slide, Sample 171B-1053A-12H-4, 125-130 cm/I (Y43). Figure 14 is to the same scale as Figure 13. 15, 16, 17. Skolchorate cyst sample/slide, Sample 171B-1053A-14H-4, 125-129 cm/I (D25). Figures 16 and 17 are to the same scale as Figure 15. Click on image for close-up.
