Plate P14. Suberinite, fungal tissues. 1. T5819; Hole 1116D; 703.23 mbsf. Fungal resting spore (sclerotium). Occurrences of sclerotia and teleutospores are highly characteristic of Tertiary and Holocene coals and, to a lesser extent, organic-rich sediment

Plate P14. Suberinite, fungal tissues. 1. T5817; Hole 1109D; 688.21 mbsf. Wood tissue showing the outer layers with suberinite present in the upper part of the field and gelified tissue in the lower part of the field (reflected light; field width = 0.22 mm; mean vitrinite reflectance = 0.40%).
