Plate P14. Suberinite, fungal tissues. 1. T5819; Hole 1116D; 703.23 mbsf. Fungal resting spore (sclerotium). Occurrences of sclerotia and teleutospores are highly characteristic of Tertiary and Holocene coals and, to a lesser extent, organic-rich sediment

Plate P14. Suberinite, fungal tissues. 3. T5828; Hole 1115D; 241.48 mbsf. Telovitrinite (dark gray) with abundant pale gray fungal hyphae invading the tissues. Fungal attack is common, but the hyphae do not always show optical contrast as strong as in this field (reflected light; field width = 0.22 mm; mean telovitrinite reflectance = 0.15%; fungal tissue reflectance = 0.66%).
