Plate P6. Suberinite and cutinite. 4. T5822; Hole 1114A; 64.72 mbsf. Same as figure 3, but in fluorescence mode. Cutinite probably seen is section oblique to the surface of the wood. The section angle has emphasized small reentrants within the outer layers. Fluorescence of the cutinite is strong, and the form indicates that it is associated with wood rather than leaf tissues (reflected light; field width = 0.22 mm; mean vitrinite reflectance = 0.33%).
