Plate P7.
Vitrinite, pyrite, and oil inclusions. 1. T5863; Hole 1118A;
744.27 mbsf. Telovitrinite with fluorescing cell walls and abundant layers of
pyrite. This plate has been exposed to illustrate the vitrinite and figure 3 to
show the pyrite (reflected light; field width = 0.22 mm; mean vitrinite
reflectance = 0.36%).
