Plate P9. Coal and shaly coal. 4. T5818; Hole 1109D; 969.89 mbsf. Same as figure 3, but in fluorescence mode. The telovitrinite shows weak fluorescence from some layers, and the resinite, sporinite, and liptodetrinite all show intense yellow fluorescence. The weakly fluorescing tissues may represent suberinite-like layers or could have affinities to cutinite (reflected light; field width = 0.22 mm; telovitrinite reflection = 0.30%).
