Figure F6. Quartz-alkali feldspar intergrowth found in Sample 200-1224F-3R-1, 14–16 cm, from lithostratigraphic Unit 1. Myr = myrmekite, Pl = plagioclase, Cpx = clinopyroxene, D-Gl = devitrified glass; Mt = Ti-magnetite.
