Plate P5. Cell walls transitional to suberinite. 1. T5809; Hole 1109D; 387.86 mbsf. Telovitrinite with fluorescing cell walls and a prominent pyrite lens. Some of the fluorescing tissues are similar to those in Plates P3, p.25, and P4, p.26, but some is s

Plate P5. Cell walls transitional to suberinite. 1. T5809; Hole 1109D; 387.86 mbsf. Telovitrinite with fluorescing cell walls and a prominent pyrite lens. Some of the fluorescing tissues are similar to those in Plates P3 and P4 but some is similar to suberinite (reflected light; field width = 0.22 mm; vitrinite reflectance [cell contents] = 0.31%).
